description
New revolutionary design with 0.115in. of total travel vs. a full travel lifter with 0.200in. These lifters will increase rpm by decreasing valve float and valve-train harmonics while maintaining a quiet engine. Travel reduction reduces the amount of oil that is required to fill the inside of the lifter which reduces oil aeration in the lifter on steep, fast action high lift camshaft lobes. Short travel lifters should be set with 0.065in. - 0.070in. of preload and with the normal engine growth from heat will put the operating lifter pre-load at or around half travel. Short travel lifters are designed to limit the amount of oil needed to fill the internals of the lifter which results in less oil needed compared to a full travel or other style short travel lifters. Design drastically reduces aeration of the oil producing a fully filled lifter when the lifter rolls around to the front cam lobe ramp vs. having aerated oil and then the pushrod seat dropping when the lifter hits the front cam ramp after squeezing the aeration. Machined from a steel body and designed to exceed the needs of large lift camshafts and higher valve spring pressures with a slower bleed down rate. Precision ground needle roller bearing with high chromium steel axle for long life and minimal friction. Cold forged extra long piston, precision ground and fitted for controlled leak down and pump up. High-flow disc style quick reacting check valve for better reaction at higher rpm. Race Series lifters maintain proper oil flow to the top end, increase engine rpm, valve-train stability, decreasing valve float promoting maximum valve lift. Feuling recommends Race Series lifters for engines running higher than 185 lbs. valve spring seat pressure. Feuling recommends the use of a high volume oil pump which will result in quieter, better performing lifters. Race Series lifters are compatible with either Feuling HP or Race Series oil pumps and are designed for use with both street and strip engines. Spin-Tron dyno developed and track proven. Available in standard and o.
fitment
Harley Davidson:- FLHR Road King 1999-2016
- FLHRC Road King Classic 2007-2013
- FLHRCI Road King Classic 1999-2006
- FLHRI Road King 2000-2006
- FLHRS Road King Custom 2004-2007
- FLHRSI Road King Custom 2004-2006
- FLHT Electra Glide Standard 1999-2009
- FLHTC Electra Glide Classic 1999-2005
- FLHTC Electra Glide Classic 2007-2013
- FLHTCI Electra Glide Classic 1999-2006
- FLHTCU Electra Glide Ultra Classic 2007-2016
- FLHTCUI Electra Glide Ultra Classic 1999-2006
- FLHTCUL Electra Glide Ultra Classic Low 2015-2016
- FLHTCUTG Tri Glide Ultra 2014-2016
- FLHTCUTG Tri Glide Ultra Classic 2009-2013
- FLHTI Electra Glide Standard 2003-2006
- FLHTK Electra Glide Ultra Limited 2010-2014
- FLHTK Ultra Limited 2015-2016
- FLHTKL Ultra Limited Low 2015-2016
- FLSS Softail Slim S 2017
- FLST Heritage Softail 2006
- FLSTC Heritage Softail Classic 1999-2017
- FLSTCI Heritage Softail Classic 2001-2006
- FLSTF Fat Boy 1999-2017
- FLSTFB Fat Boy Lo 2010-2016
- FLSTFBS Fat Boy S 2017
- FLSTFI Fat Boy 2001-2006
- FLSTFSE Screamin Eagle Fat Boy 2005
- FLSTFSE2 Screamin Eagle Fat Boy 2006
- FLSTI Heritage Softail 2006
- FLSTN Softail Deluxe 2005-2017
- FLSTNI Softail Deluxe 2005-2006
- FLSTNSE CVO Softail Deluxe 2014-2015
- FLSTS Heritage Springer 1999-2003
- FLSTSB Cross Bones 2008-2011
- FLSTSC Softail Springer Classic 2005-2007
- FLSTSCI Softail Springer Classic 2005-2006
- FLSTSE CVO Softail Convertible 2010
- FLSTSE2 CVO Softail Convertible 2011
- FLSTSE3 CVO Softail Convertible 2012
- FLSTSI Heritage Springer 2001-2003
- FLTR Road Glide 1999-2002
- FLTR Road Glide 2007-2009
- FLTRI Road Glide 1999-2006
- FLTRU Road Glide Ultra 2011-2013
- FLTRU Road Glide Ultra 2016-2017
- FLTRX Road Glide 2015-2017
- FLTRX Road Glide Custom 2010-2013
- FLTRXS Road Glide Special 2015-2017
- FXD Dyna Super Glide 1999-2005
- FXD Dyna Super Glide 2007-2010
- FXDB Street Bob 2007-2017
- FXDBI Street Bob 2006
- FXDC Super Glide Custom 2005
- FXDC Super Glide Custom 2007-2014
- FXDCI Super Glide Custom 2005-2006
- FXDF Fat Bob 2008-2017
- FXDFSE CVO Dyna Fat Bob 2009
- FXDFSE2 CVO Dyna Fat Bob 2010
- FXDI Dyna Super Glide 2004-2006
- FXDI35 Dyna 35th Anniversary Super Glide 2006
- FXDL Dyna Low Rider 1999-2005
- FXDL Dyna Low Rider 2007-2009
- FXDL Low Rider 2014-2017
- FXDLI Dyna Low Rider 2004-2006
- FXDLS Low Rider S 2016-2017
- FXDS-Conv Dyna Convertible 1999-2000
- FXDSE Screamin Eagle Dyna 2007
- FXDSE2 Screamin Eagle Dyna 2008
- FXDWG Dyna Wide Glide 1999-2005
- FXDWG Dyna Wide Glide 2007-2008
- FXDWG Dyna Wide Glide 2010-2017
- FXDWG2 2001
- FXDWG3 2002
- FXDWGI Dyna Wide Glide 2004-2006
- FXDX Dyna Super Glide Sport 1999-2005
- FXDXI Dyna Super Glide Sport 2004-2005
- FXDXT Dyna Super Glide T-Sport 2001-2003
- FXSB Breakout 2017
- FXSE CVO Pro Street Breakout 2017
- FXST Softail Standard 2000-2007
- FXSTB Night Train 2000-2009
- FXSTBI Night Train 2001-2006
- FXSTC Softail Custom 2007-2010
- FXSTD Softail Deuce 2000-2007
- FXSTDI Softail Deuce 2001-2006
- FXSTI Softail Standard 2001-2006
- FXSTS Springer Softail 2000-2006
- FXSTSI Springer Softail 2001-2006
- XL1200C Sportster 1200 Custom 2000-2019
- XL1200CX Roadster 2016-2020
- XL1200L Sportster 1200 Low 2006-2011
- XL1200N Sportster 1200 Nightster 2007-2012
- XL1200NS Iron 1200 2018-2020
- XL1200R Sportster 1200 Roadster 2004-2008
- XL1200S Sportster 1200 Sport 2000-2003
- XL1200T SuperLow 1200T 2014-2017
- XL1200V Seventy-Two 2012-2016
- XL1200X Forty-Eight 2010-2020
- XL1200XS Forty-Eight Special 2018-2019
- XL50 50th Anniversary Sportster 2007
- XL883 Sportster 2004-2008
- XL883C Sportster 883 Custom 2000-2009
- XL883L Sportster 883 Low 2005-2010
- XL883L SuperLow 2011-2019
- XL883N Iron 883 2009-2020
- XL883R Sportster 883 Roadster 2002-2003
- XL883R Sportster 883 Roadster 2005-2007
- XLH1200 2000-2003
- XLH883 2000-2003
- XLH883HUG Sportster 883 Hugger 2000-2003
- XR1200 2009-2010
- XR1200X 2011-2012
