Name: Acuity Csi 14 x 17 Wireless Digital X-ray System
SKU: 81256

Radmedix Acuity 1417 Wireless Cassette Sized Flat Panel Direct Digital Radiographic System (Medical Solution)

Acuity 14×17 Wireless is a complete wireless, cassette sized X-Ray detector. It can easily transform any existing conventional x-ray room into an efficient Digital Radiology suite. It is portable and lightweight design requires no bulky modification and easily integrates with any manufactures original equipment. The Acuity 14×17 Wireless delivers unmatched image quality just seconds after exposure. It is a perfect solution for practices seeking to upgrade their existing x-ray room at a cost effective price. This versatile, Wireless DR Detector allows for quick and easy integration and multi-purpose clinical applications.

FEATURES

Slim Cassette size 14×17″ Detector
Highly reliable and stable operation
High definition by direct deposition CsI
WiFi image transfer
Fast image acquisition time less than 3 Seconds
AED – Automatic Exposure Detection
Wireless Interface AccuVueMED Acquisition Workstation (UserPC)
Multi-channel Room Sharing Interface

Slim Dual Battery Charger

Two Acuity DR 1417 batteries can be simultaneously charged with the Slim Dual Battery Charger. LED display allows for easy check of the battery level and with its light and compact design, user portability and usability is increased. The Charger comes standard with Acuity DR 1417 detector.

High Sharpness Images by Direct Deposited CsI

Directly deposited CsI can provide clearer images at lowest dispersion compared to a conventional CsI and GOS scintillator. RadmediX promises its users the best image quality with its design of low noise TFT, electrons and optimized CsI thickness.

Better DQE Performance in Higher Spatial Frequencies

RadmediX with its directly deposited columnar structured Csl TFT provides outstanding high quality images with high DQE performance in high spatial frequency range.
_{*DQE measurements condition : RQA-5 (Typical 2.6 uGy)}

Durability

Mechanically optimized and engineered with metal unibody structure, Acuity DR 1417 has safety at 3.3 ft height drop test. Also, protection suit is separately provided to protect the detector in various situations such as hospitals and mobile environments. Ergonomically designed protection suit provides optimum usability in x-ray environments. X-ray environments efficiency considered package of a protection suit and a compatible tablet mounter further adds to user convenience.

Details:

Detector: 14 x17 Wireless Cassette Sized Detector
Detector Type- TFT Gadox/CsI Flat Panel Detector
Detecting Area- 14x17
Pixel Resolution- 2560 x3072 pixels
Preview Time- <5 seconds after exposure
A/D Conversion- 14 bits
Communication – Wireless
Interface- Lossless AED
Battery Performance- 4hr @ 180 exposures per hr. 720 images
Weight- 7.0 lbs. (*varies with standby time*)

DR manufactures warranty- (3) years panel & (1) year software support.

AccuVue Software Features:

Modern graphical user interface (GUI) adaptable to almost any language
Touchscreen operation – to ensure quick and efficient work and a smooth workflow
Fully integrated radiographic positioning guide for each examination in human and veterinary medicine incl. comprehensive notes, photos, videos and correct X-ray images
Perfect images at all time – generally no adjustment required
Integrated software for automatic image optimization
Professional, adaptable image processing for each individual examination to obtain best possible image settings for the needs of each customer
Completely integrated dicom Viewer for image diagnosis further processing and storage of image in an SQL database incl. image manipulations, export options, layout adjustments, freely configurable user interface and much more
Step less zoom, PAN, magnifier, ROI, crop, rotate, mirror etc.
Insertion of image annotations, e.g. free texts, arrows, ellipses etc.
Measuring of distances, angles, areas and density
Exposure Indicator relative to dose
Dicom Send/Store
Dicom Patient CD
Dicom Modality Worklist,
